Products > Sensor Connector > M8 Series > M8 4 Pin Male Right Angle Field Assembly Plug, A Code Unshielded, Solder Cup
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Plug |
| Number of Positions | 4 |
| Contact Type | Male Pin |
| Key | A |
| Orientation | Right Angle |
| Shell Size | M8 |
| Mounting Type | Cable Type |
| Fastening Type | Threaded |
| Contact Termination | Outer Screw |
| Materials | |
|---|---|
| Shell Material | PA66+GF |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 30V |
| Rated Current | 1.5A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- Space-Saving Design: Right-angle configuration ideal for compact or constrained spaces.
- 4-Pin Layout: Provides additional connection points for more complex signal needs.
- A Code: Commonly used for signal applications with standard A Code configuration.
- Unshielded: Cost-effective for environments with low electromagnetic interference.
- Screw Termination: Offers a robust and stable connection with screw-secured fittings.
- Field-Wireable: Facilitates easy and flexible on-site wiring and adjustments.
