RHT-634-1412-06

M8 Male Panel Mount Receptacle 6 Pin A Code Rear Fastened Straight PCB M8

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 6 Pins (A-Coded): Provides multiple connections for complex signal or power needs with precise alignment.
  2. A-Coded: Ensures correct connection orientation and compatibility.
  3. Rear Fastened: Allows secure attachment to the panel from the rear side.
  4. Straight Orientation: Facilitates direct mounting on a PCB (Printed Circuit Board).
  5. Panel Mount Design: Ensures stability and durability for industrial applications.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeMale Pin
Number of Positions6
KeyA
Contact TerminationThrough Hole
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Panel Mount Receptacle Rear Fastened Straight PCB Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
