Products > Sensor Connector > Mini Change 7/8" Female Cable Connector Unshielded Screw Termination Straight 4 Pin

78014-04-PG13.5
Mini Change 7/8" Female Cable Connector Unshielded Screw Termination Straight 4 Pin

Efficiently connect your cables with this Mini Change 7/8" Female Cable Connector. Featuring unshielded screw termination and straight 4-pin design, this connector ensures a secure and reliable connection for your electronic devices.

Color
  1. Silver
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog
    • Certificate

    Product certification

    1. General
    2. Mechanical
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypePlug
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions4
    Fastening TypeThreaded
    Mounting TypeCable Type
    Contact TerminationScrew

    Mechanical

    Wire Gauge or Range6~8mm

    Material

    Shell MaterialPA66+GF
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 80°C

    Electrical

    ShieldingUnshielded
    Rated Current9A
    Rated Voltage300V
