Products > Circular Connector > Mini Change 7/8" Female Cable Connector Unshielded Screw Termination Straight 6 Pin

78014-06-PG13.5
Mini Change 7/8" Female Cable Connector Unshielded Screw Termination Straight 6 Pin

Color
  1. Silver
Number of Positions
  1. 3
  2. 4
  3. 5
  4. 6
Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog

    Efficiently connect cables with this Mini Change 7/8" Female Cable Connector. Unshielded with screw termination, this straight 6 pin connector ensures a reliable and secure connection. Perfect for various industrial applications.

    1. General
    2. Mechanical
    3. Material
    4. Environmental
    5. Electrical

    General

    Connector TypePlug
    OrientationStraight
    Contact TypeFemale Pin
    Number of Positions6
    Contact TerminationScrew

    Mechanical

    Wire Gauge or Range6~8mm
    Fastening TypeThreaded
    Mounting TypeCable Type

    Material

    Shell MaterialPA66+GF
    Contact FinishGold
    Contact MaterialCopper Alloy

    Environmental

    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 80°C

    Electrical

    ShieldingUnshielded
    Rated Current9A
    Rated Voltage300V
    Каталог разъемов RENHOTEC 2PM [EN][RU] Download
    RENHOTEC M-Series Connector Catalog [EN][CN] Download
