Products > Energy Storage Connector > 12mm Power Entry Connector Receptacle Outer Screw(M10) Red
12mm Power Entry Connector Receptacle Outer Screw(M10) Red - RHT-S012-T02-RD
12mm Power Entry Connector Receptacle Outer Screw(M10) Red - RHT-S012-T02-RD
12mm Power Entry Connector Receptacle Outer Screw(M10) Red product image

RHT-S012-T02-RD

12mm Power Entry Connector Receptacle Outer Screw(M10) Red

Color:

BlackOrangeRed

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions1
    OrientationStraight
    Contact Size12mm
    Mounting TypePanel Mount
    Mounting FeatureFlange
    Contact TerminationOuter Screw
    ColorRed
    Materials
    Shell MaterialNylon
    Contact MaterialT2
    Contact FinishSilver
    Electrical
    Rated Voltage1500V
    Rated Current350A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-40°C ~ + 125°C

    Product excerpt

    1. 12mm energy storage connector with 350A current rating
    2. M10 outer screw for secure and reliable connections
    3. Red housing for clear identification in power systems
    4. Designed for high-current energy storage and distribution
    5. Robust performance in industrial and demanding environments

    Certification

    M.2022.206.C77197 CE Certificate Energy Storage Connectors Cable Download
    Renhotec Energy Storage Connector CE Certificate [EN] Download

    Catelog

    RENHOTEC Battery Storage Connector Catalog [EN] Download
    RENHOTEC EV Product Catalog [EN] Download
    Drawing for 12mm Power Entry Connector Receptacle Outer Screw(M10) Download
