Products > Energy Storage Connector > 6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Orange
6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Orange - RHT-S006-T02-OG
6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Orange - RHT-S006-T02-OG
6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Orange product image

RHT-S006-T02-OG

6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Orange

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions1
OrientationStraight
Contact Size6mm
Mounting TypePanel Mount
Mounting FeatureFlange
Contact TerminationOuter Screw
ColorOrange
Materials
Shell MaterialNylon
Contact MaterialT2
Contact FinishSilver
Electrical
Rated Voltage1000V
Rated Current120A
ShieldingUnshielded
Environmental
Ingress ProtectionIP54
Operating Temperature-40°C ~ + 125°C

Product excerpt

  1. 6.0mm power entry connector, 120A rating
  2. M6 outer screw terminal for secure connection
  3. High-visibility orange housing for easy identification
  4. Ideal for energy storage and high-power applications
  5. Reliable and robust design for industrial environments

Certification

M.2022.206.C77197 CE Certificate Energy Storage Connectors Cable Download
Renhotec Energy Storage Connector CE Certificate [EN] Download

Catelog

RENHOTEC Battery Storage Connector Catalog [EN] Download
RENHOTEC EV Product Catalog [EN] Download
Drawing for 6.0mm Power Entry Connector 120A Receptacle Outer Screw(M6) Download
