Products > Energy Storage Connector > 6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Black
- Overview
- Technical data
- Catalog
Upgrade your power connections with this 6.0mm Power Entry Connector. Designed to handle up to 60A, it features a right-angled cable plug suitable for 10mm² unshielded cables. The sleek black finish adds a professional touch to your setup.
General
Connector Type | Plug |
Orientation | Right Angle |
Number of Positions | 1 |
Contact Size | 6mm |
Contact Termination | Crimp |
Color | Black |
Electrical
Rated Voltage | 1000V |
Rated Current | 60A |
Shielding | Unshielded |
Mechanical
Mounting Type | Cable Type |
Wire Gauge or Range | 10mm² |
Material
Shell Material | Nylon |
Contact Material | T2 |
Contact Finish | Silver |
Environmental
Ingress Protection | IP54 |
Operating Temperature | -40°C ~ + 125°C |
