Products > Energy Storage Connector > 6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Red Punch Processing Terminals
6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Red Punch Processing Terminals - RHT-P006-C10-RD-T
6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Red Punch Processing Terminals - RHT-P006-C10-RD-T
6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Red Punch Processing Terminals product image

RHT-P006-C10-RD-T

6.0mm Power Entry Connector 60A Cable Plug Right Angled 10mm² Unshielded Cable Red Punch Processing Terminals

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypePlug
Number of Positions1
OrientationRight Angle
Contact Size6mm
Mounting TypeCable Type
Contact TerminationCrimp
Terminal Processing TypePunch Processing
Wire Gauge or Range10mm²
ColorRed
Materials
Shell MaterialNylon
Contact MaterialT2
Contact FinishSilver
Electrical
Rated Voltage1000V
Rated Current60A
ShieldingUnshielded
Environmental
Ingress ProtectionIP54
Operating Temperature-40°C ~ + 125°C

Product excerpt

  1. 6.0mm right-angled energy storage connector, rated for 60A
  2. Designed for 10mm² unshielded cable
  3. Red housing, ideal for energy storage applications
  4. Punch-processed terminals ensure secure and efficient connections
  5. Suitable for high-power energy storage and industrial uses

Certification

M.2022.206.C77197 CE Certificate Energy Storage Connectors Cable Download
Renhotec Energy Storage Connector CE Certificate [EN] Download

Catelog

RENHOTEC Battery Storage Connector Catalog [EN] Download
RENHOTEC EV Product Catalog [EN] Download
Drawing for 6.0mm Power Entry Connector Cable Plug Right Angled Unshielded Cable Punch Processing Terminals Download
