Products > Energy Storage Connector > 8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Black Punch Processing Terminals
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Plug |
| Number of Positions | 1 |
| Orientation | Right Angle |
| Contact Size | 8mm |
| Mounting Type | Cable Type |
| Contact Termination | Crimp |
| Terminal Processing Type | Punch Processing |
| Wire Gauge or Range | 25mm² |
| Color | Black |
| Materials | |
|---|---|
| Shell Material | Nylon |
| Contact Material | T2 |
| Contact Finish | Silver |
| Electrical | |
|---|---|
| Rated Voltage | 1000V |
| Rated Current | 120A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP54 |
| Operating Temperature | -40°C ~ + 125°C |
Product excerpt
- 8.0mm power entry connector, rated for 120A current
- Right-angled design for compact installations
- Designed for 25mm² cable, ensuring efficient power delivery
- Black housing with punch processing terminals for durability
- Ideal for power entry in various high-current applications
