8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Red Lath Machining Terminals - Renhotec

Energy Storage Connector > 8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Red Lath Machining Terminals

RHT-P008-C25-RD-C

8.0mm Power Entry Connector 120A Cable Plug Right angled 25mm² Red Lath Machining Terminals

Get a Quote

Overview
Technical data
Certification
Download

Product certification

Product excerpt

8.0mm energy storage connector, rated for 120A current
Right-angled design for space efficiency
Compatible with 25mm² cables for optimal power transmission
Red housing with lath machining terminals for enhanced durability
Suitable for energy storage and high-current applications

GeneralMaterialMechanicalEnvironmentalElectrical

General
Connector Type	Plug
Orientation	Right Angle
Number of Positions	1
Contact Size	8mm
Contact Termination	Crimp
Terminal Processing Type	Lathe Processing
Color	Red

Material
Shell Material	Nylon
Contact Material	T2
Contact Finish	Silver

Mechanical
Mounting Type	Cable Type
Wire Gauge or Range	25mm²

Environmental
Ingress Protection	IP54
Operating Temperature	-40°C ~ + 125°C

Electrical
Rated Voltage	1000V
Rated Current	120A
Shielding	Unshielded

Certification

Renhotec Energy Storage Connector CE Certificate [EN]	Download
Drawing for 8.0mm Power Entry Connector Cable Plug Right angled Lath Machining Terminals	Download

Catelog

RENHOTEC Battery Storage Connector Catalog [EN]	Download
RENHOTEC EV Product Catalog [EN]	Download
