Products > Energy Storage Connector > 8.0mm Power Entry Connector 200A Receptacle Outer Screw(M8) Orange

RHT-S008-T02-OG
8.0mm Power Entry Connector 200A Receptacle Outer Screw(M8) Orange

Compare

Product Type

Only 4 products can be compared at a time. Please select the product you want to replace.

    • Overview
    • Technical data
    • Catalog

    This 8.0mm Power Entry Connector features a 200A rating, receptacle type, outer screw (M8) orientation, and vibrant orange color. Ideal for high-powered applications requiring a reliable and secure connection.

    1. General
    2. Electrical
    3. Mechanical
    4. Material
    5. Environmental

    General

    Connector TypeReceptacle
    OrientationStraight
    Number of Positions1
    Contact Size8mm
    Contact TerminationOuter Screw
    ColorOrange

    Electrical

    Rated Voltage1000V
    Rated Current200A
    ShieldingUnshielded

    Mechanical

    Mounting TypePanel Mount
    Mounting FeatureFlange

    Material

    Shell MaterialNylon
    Contact MaterialT2
    Contact FinishSilver

    Environmental

    Operating Temperature-40°C ~ + 125°C
