M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup - RHT-634-3084-02
M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup - RHT-634-3084-02
M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup product image
M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup product image
M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup product image

RHT-634-3084-02

M16 2 Pin Female Straight Panel Mount Receptacle, A Code Front Fastened, Solder Cup

Number of Positions:

  • Technical data
  • Overview
  • Certification
  • Download
General
Connector TypeReceptacle
Number of Positions2
Contact TypeFemale Pin
KeyA
OrientationStraight
Shell SizeM16
Mounting TypePanel Mount
Fastening TypeThreaded
Contact TerminationSolder Cup
Materials
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact MaterialCopper Alloy
Contact FinishGold
Electrical
Rated Voltage250V
Rated Current5A
ShieldingUnshielded
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C

Product certification

Product excerpt

High-quality M16 female panel mounting socket with 6 positions, A code, front fastened, and straight solder connection. Ideal for secure and reliable electrical connections in various applications.

Certification

Renhotec REACH Test Report Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
