product image

RHT-634-3233-03

M8 3 Pin Female Straight Panel Mount Receptacle, A Code Rear Fastened, PCB M8

Color:

Silver

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product certification

Product excerpt

  1. 3 Pins (A-Coded): Ensures secure and precise connections.
  2. A-Coded: Guarantees correct orientation and compatibility.
  3. Rear Fastened: Allows for secure attachment to the panel from the rear.
  4. Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
  5. Panel Mount Design: Provides stability and durability in various applications.
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current3A
Material
Shell MaterialCopper Alloy
General
Connector TypeReceptacle
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM8

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M8 Female Panel Mount Receptacle Rear Fastened Straight PCB Download
