Products > Sensor Connector > M8 Series > M8 3 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8
product image

RHT-634-1296-03

M8 3 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8

Color:

Silver

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product certification

Product excerpt

  1. 3 Pins (A-Coded): Provides precise alignment for signal or power connections.
  2. A-Coded: Ensures correct orientation and compatibility.
  3. Rear Fastened: Securely attaches to the panel from the rear.
  4. Straight Orientation: Facilitates direct connection to PCB (Printed Circuit Board).
  5. Solder Cup Contacts: Offers a strong, reliable connection through soldering.
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current3A
Material
Shell MaterialCopper Alloy
General
Connector TypeReceptacle
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM8

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M8 Male Panel Mount Receptacle Rear Fastened Straight Solder Cup Download
