Products > Sensor Connector > M8 Series > M8 8 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8
M8 8 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8 - RHT-634-1296-08
M8 8 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8 - RHT-634-1296-08
M8 8 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8 product image

RHT-634-1296-08

M8 8 Pin Male Straight Panel Mount Receptacle, A Code Rear Fastened, Solder Cup M8

Number of Positions:

34568

Complete the form below for a quick professional response. We guarantee to contact you within 24 hours.


    Get a Quote
    Products >
    • Technical data
    • Overview
    • Certification
    • Download
    GeneralMaterialsElectricalEnvironmental
    General
    Connector TypeReceptacle
    Number of Positions8
    Contact TypeMale Pin
    KeyA
    OrientationStraight
    Shell SizeM8
    Mounting TypePanel Mount
    Mounting FeatureBulkhead
    Fastening TypeThreaded
    Contact TerminationSolder
    Materials
    Shell MaterialCopper Alloy
    Shell FinishZinc Plated
    Contact MaterialCopper Alloy
    Contact FinishGold
    Electrical
    Rated Voltage30V
    Rated Current1.5A
    ShieldingUnshielded
    Environmental
    Ingress ProtectionIP67
    Operating Temperature-25°C ~ + 85°C

    Product certification

    ×

    Product excerpt

    1. 8 Pins (A-Coded): Supports multiple connections with precise alignment.
    2. A-Coded: Ensures correct orientation and compatibility.
    3. Rear Fastened: Provides secure attachment to the panel from the rear.
    4. Straight Orientation: Facilitates direct and straightforward PCB mounting.
    5. Solder Cup Contacts: Ensures robust and reliable connections through soldering.

    Certification

    Renhotec REACH Test Report Download

    Catelog

    RENHOTEC M-Series Connector Catalog [EN][CN] Download
    Drawing for M8 Male Panel Mount Receptacle Rear Fastened Straight Solder Cup Download
