Products > Sensor Connector > M8 Series > M8 5 Pin Male Straight Panel Mount Receptacle, B Code Rear Fastened, Solder Cup M8
- Technical data
- Overview
- Certification
- Download
| General | |
|---|---|
| Connector Type | Receptacle |
| Number of Positions | 5 |
| Contact Type | Male Pin |
| Key | B |
| Orientation | Straight |
| Shell Size | M8 |
| Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead |
| Fastening Type | Threaded |
| Contact Termination | Solder |
| Materials | |
|---|---|
| Shell Material | Copper Alloy |
| Shell Finish | Zinc Plated |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Electrical | |
|---|---|
| Rated Voltage | 60V |
| Rated Current | 3A |
| Shielding | Unshielded |
| Environmental | |
|---|---|
| Ingress Protection | IP67 |
| Operating Temperature | -25°C ~ + 85°C |
Product certification
Product excerpt
- 5 Pins (B-Coded): Supports multiple connections with precise alignment.
- B-Coded: Ensures correct orientation and compatibility.
- Rear Fastened: Secures attachment to the panel from the rear side.
- Straight Orientation: Facilitates direct mounting on PCB (Printed Circuit Board).
- Solder Cup Contacts: Provides durable and reliable connections through soldering.
Certification
 Renhotec REACH Test Report |
Download |
