RHT-634-3150-03

M8 Female Panel Mount Receptacle 3 Pin A Code Front Fastened Straight Solder Cup Open Hole M10

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 8 Pins (A-Coded): Supports multiple signal or power connections with secure alignment.
  2. A-Coded: Ensures correct orientation and compatibility with other A-coded devices.
  3. Front Fastened: Allows easy installation from the front side of the panel.
  4. Straight Design: Optimized for direct and efficient PCB mounting.
  5. Open Hole Design: Provides flexibility in mounting configurations for varied applications.。
  6. Compact and Durable: Suitable for space-constrained environments, ensuring long-lasting performance.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions3
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Panel Mount Receptacle Front Fastened Straight Solder Cup Open Hole Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
