product image

RHT-634-3150-08

M8 Female Panel Mount Receptacle 8 Pin A Code Front Fastened Straight Solder Cup Open Hole M10

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. M8 8-pin female connector, A-coded for reliable multi-signal transmission
  2. Front fastening panel mount for easy and secure installation
  3. Straight solder cup ensures durable and stable wiring
  4. M10 open hole design, suitable for industrial and automation systems
  5. Ideal for sensors, data transmission, and multi-signal cable integration applications
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions8
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Panel Mount Receptacle Front Fastened Straight Solder Cup Open Hole Download
