product image

RHT-634-3150-06

M8 Female Panel Mount Receptacle 6 Pin A Code Front Fastened Straight Solder Cup Open Hole M10

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. M8 6-pin female connector, A-coded for reliable signal and data transmission
  2. Front fastening panel mount for quick and secure installation
  3. Straight solder cup connection ensures durable wiring
  4. M10 open hole design, ideal for industrial automation systems
  5. Suitable for sensors, data transmission, and cable system integration
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypeReceptacle
OrientationStraight
Contact TypeFemale Pin
Number of Positions6
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypePanel Mount
Mounting FeatureBulkhead
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingUnshielded
Rated Current1.5A
Rated Voltage30V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Female Panel Mount Receptacle Front Fastened Straight Solder Cup Open Hole Download
