RHT-634-3232-03

M8 Male Field Wireable Plug 3 Pin A Code Shielded Straight Solder Cup

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 3 Pins (A-Coded): Ensures proper alignment and secure connections for signal transmission.
  2. Shielded Design: Provides protection against electromagnetic interference (EMI) for reliable data transmission.
  3. Field Wireable: Allows for easy on-site assembly, making it adaptable for custom cable lengths.
  4. Solder Cup Contacts: Simplifies wiring by enabling a secure connection via soldering.
  5. Straight Orientation: Designed for straightforward cable routing in tight spaces.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeMale Pin
Number of Positions3
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingShielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Field Wireable Plug A Code Shielded Straight Solder Cup Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
