product image

RHT-634-3232-08

M8 Male Field Wireable Plug 8 Pin A Code Shielded Straight Solder Cup

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 8 Pins (A-Coded): Suitable for transmitting multiple signals or data streams with secure and precise alignment.
  2. Shielded Design: Protects against electromagnetic interference (EMI), ensuring data integrity.
  3. Field Wireable: Enables easy, on-site assembly, allowing for custom cable lengths and installations.
  4. Solder Cup Contacts: Facilitates quick and secure wiring via soldering.
  5. Straight Orientation: Ideal for tight spaces, providing straightforward cable management.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeMale Pin
Number of Positions8
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingShielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Field Wireable Plug A Code Shielded Straight Solder Cup Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
