product image

RHT-634-3232-05

M8 5 Pin Male Straight Field Assembly Plug, B Code Shielded, Solder Cup

Color:

Silver

Number of Positions:

  • Overview
  • Technical data
  • Certification
  • Download

Product certification

Product excerpt

  1. 5 Pins (B-Coded): Specialized for industrial networking and data communication.
  2. Shielded Design: Provides protection against electromagnetic interference (EMI) for stable and secure connections.
  3. Field Wireable: Allows for easy on-site assembly and custom cable lengths.
  4. Solder Cup Contacts: Simplifies wiring with a reliable soldering method.
  5. Straight Orientation: Ensures simple cable routing in compact spaces.
EnvironmentalElectricalMaterialGeneralMechanicalShell
Environmental
Ingress ProtectionIP67
Electrical
Rated Current3A
Material
Shell MaterialCopper Alloy
General
Connector TypePlug
Mechanical
Fastening TypeThreaded
Shell
Shell SizeM8

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
Drawing for M8 Male Field Wireable Plug A Code Shielded Straight Solder Cup Download
