Products > Circular Connector > M8 Male Field Wireable Plug 6 Pin A Code Shielded Straight Solder Cup
product image

RHT-634-3232-06

M8 Male Field Wireable Plug 6 Pin A Code Shielded Straight Solder Cup

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 6 Pins (A-Coded): Ensures precise alignment and accommodates multiple signal or power connections.
  2. Shielded Design: Provides protection against electromagnetic interference (EMI) for stable data transmission.
  3. Field Wireable: Allows for convenient on-site assembly and customization of cable lengths.
  4. Solder Cup Contacts: Facilitates secure and reliable wiring via soldering.
  5. Straight Orientation: Designed for straightforward cable routing in confined spaces.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeMale Pin
Number of Positions6
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingShielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Field Wireable Plug A Code Shielded Straight Solder Cup Download
