RHT-634-3232-04

M8 Male Field Wireable Plug 4 Pin A Code Shielded Straight Solder Cup

Color:

Silver

Number of Positions:

34568
Get a Quote
Products >
  • Overview
  • Technical data
  • Certification
  • Download

Product certification

×

Product excerpt

  1. 4 Pins (A-Coded): Ensures secure and accurate signal transmission in automation and sensor applications.
  2. Shielded Design: Protects against electromagnetic interference (EMI), enhancing data reliability.
  3. Field Wireable: Easy on-site assembly allows for custom cable lengths and configurations.
  4. Solder Cup Contacts: Simplifies the wiring process, ensuring a secure and durable connection.
  5. Straight Orientation: Enables straightforward cable management, especially in confined spaces.
GeneralMaterialMechanicalEnvironmentalShellElectrical
General
Connector TypePlug
OrientationStraight
Contact TypeMale Pin
Number of Positions4
KeyA
Contact TerminationSolder Cup
Material
Shell MaterialCopper Alloy
Shell FinishZinc Plated
Contact FinishGold
Contact MaterialCopper Alloy
Mechanical
Fastening TypeThreaded
Mounting TypeCable Type
Environmental
Ingress ProtectionIP67
Operating Temperature-25°C ~ + 85°C
Shell
Shell SizeM8
Electrical
ShieldingShielded
Rated Current3A
Rated Voltage60V

Certification

M8 M12 M16 Connector AGC07686211202-002 REACH Download
Drawing for M8 Male Field Wireable Plug A Code Shielded Straight Solder Cup Download

Catelog

RENHOTEC M-Series Connector Catalog [EN][CN] Download
